GP-50 RGB LED Point Light Source

50MM LED Point Light Application

  • Hotels, restaurants, night clubs,
  • Coffee / wine bars, shopping malls
  • Building Facade, Garden
  • Plaza Hotel Commercial Center; holiday decoration

Specification

The GP-50 RGB LED Point Light Source is a type of LED lighting module that consists of a single LED point light source in a compact and rugged housing. It is designed to provide high-quality lighting effects in a variety of applications.

    SKU     GPX-50RGB            |      GPX-50RGBW
    Operating voltage                                        DC24V
    Power/Bulb    1.44W                           |       1.92W
    SMD Type     SMD5050*6RGB        |SMD5050*6RGB+4W
    Lamp Qty/string     100PCS/String
    Control Mode     2000-6500K, SPI, DMX512
    LED Chip     Epistar, Cree, Osram…..
    Material     PVC+PC
    Diameter   Φ50mm*14mm
    Beam angle     120°
    IP Rate     IP67
    Cable Type   2x1mm²+3×0.35mm²
    Operating Temp     -30℃ to 55℃

Product Feature

1. GP-DX50 Pixel Light Installation: Easy to install.
2. LED point light With features of high brightness, low power dissipation, long lifespan, low voltage, low decline, and colorful.
3. Secondary Injection LED RGB Dot Light Different installation methods may compose different dynamic effects of different colors’ characters and designs

Dimension Drawing

Installation

Connection

Introduction

The GP-50 RGB LED Point Light Source can produce a wide range of colors, including red, green, and blue, as well as a range of other colors by mixing these primary colors. It can be controlled using a DMX512 protocol, allowing for precise control over the color, brightness, and intensity of the light.

The device is designed for easy installation and can be mounted using a variety of mounting brackets and accessories. It is also weather-resistant, making it suitable for use in outdoor applications.

The GP-50 RGB LED Point Light Source is commonly used in a range of lighting applications, including architectural lighting, stage lighting, and event lighting. It can be used to create dynamic color washes, highlight architectural features, and add visual interest to stage performances and events.



Overall, the GP-50 RGB LED Point Light Source is a powerful and versatile lighting module that is ideal for use in a wide range of applications where high-quality lighting effects are required.
