Here is more information on LED Point Light Source :
• GPX provides an effective and visually appealing alternative to traditional strip lights and bulb lighting. The tiny individual LED pixels allow for extremely fine-tuned patterns, graphics, and animations that are not possible with standard lights.
• Common applications include signage, architectural features, wayfinding paths, decorative accents, and stage or event lighting. The vibrant colors, narrow beam angles, and positioning flexibility make them ideal for creating eye-catching designs and effects.
• LED Point Light is available in various pixel pitches ( distance between LEDs), depending on the desired resolution and size of the lighting application. Smaller pixel pitches offer higher resolution and sharper images at the cost of greater light and power requirements.
• RGB LED pixels produce red, green, and blue light which can be mixed in different intensities to create virtually any color. RGBW pixels also include a white LED for even brighter illumination and a wider color gamut.
• Advanced LED pixel lights can be controlled via DMX, Bluetooth, or WiFi to enable remote programming and synchronization with audio/video. This allows for dynamic effects and shows that can be precisely timed.
• While generally more expensive initially, LED pixel dot lights have low energy consumption and maintenance needs that make them a cost-effective long-term investment for commercial applications that require precise, vibrant, and continuously changing illumination.
| SKU | GPX-DS40/RGB/RGBW |
| Operating voltage | DC24V |
| Power/Bulb | 1.44W/1.92W |
| SMD Type | SMD3535*6RGB /SMD3535*6RGB+2 White LED |
| Lamp Qty/string | 100 PCS/String |
| Control Mode | 2000-6500K, SPI, DMX512 |
| LED Chip | Epistar, Cree, Osram….. |
| Luminous flux | 160LM |
| Material | PVC+PC |
| Diameter | Φ40mm*11.4mm |
| Beam angle | 120° |
| IP Rate | IP67 |
| Cable Type | 2×0.75mm²+3×0.3mm² |
| Operating Temp | -40℃ to 55℃ |
1. Led point light is High luminous efficiency, a narrow spectrum, and good mono-chromaticity.
2. It can randomly program and control multiple synchronous changes, and can achieve full-color changes such as synchronous colorful, jumping, scanning, and flowing water.
3. High color rendering,’ vivid color, excellent color reduction ability
4. Anti-Fire rating to 94V-0, Anti-UV
5. Better heat dissipation, Precision constant current
6. Led Facade Lighting has CE and RoHS certification
7. OEM&ODM are available
