DC24V 140MM RGB LED Pixel Dot Light for Architectural Facade Projects

140MM LED Pixel Dot Light Application

  • Bridge outlines, buildings, hotels, billboards, curtain walls, cultural and tourist attractions, night lights
  • Screen of extra exterior sign and building, Lighting for city signage.
  • Interior decorative lighting of Bar, KTV entertainment place and stage decoration.

Specification

DC24V LED Pixel Dot Light are a type of LED lighting system that consists of small, individually addressable LED modules that can be arranged in various configurations to create dynamic lighting effects. These lights are commonly used for decorative lighting, signage, and stage lighting.

DC24V refers to the voltage required to power the LED modules. The use of a low voltage power supply reduces the risk of electrical shock and makes the system safer to use in a wide range of settings.

    SKU     GPX-D140/RGB/RGBW
    Operating voltage      DC24V
    Power/Bulb     3W/6W
    SMD Type     SMD3535*RGB /SMD3535*RGB+White LED
    Lamp Qty/string     20 PCS/String
    Control Mode     2000-6500K, SPI, DMX512
    LED Chip     Epistar, Cree, Osram…..
    Luminous flux    288-432LM
    Material     PC
    Diameter    Φ140mm*100mm,  Φ113mm*90mm
    Beam angle     120°
    IP Rate     IP67
    Cable Type     2×0.75mm²+3×0.3mm²
    Operating Temp     -40℃ to 55℃

Product Feature

1: The shell of this DC24V LED Pixel Dot Light is made of die-cast aluminum and high-grade tempered glass, which has outstanding impact resistance, heat resistance, cold resistance, and excellent dielectric properties
2: Energy saving, low power consumption, long service life, soft light color, uniform, and bright color, no glare, no mercury, sodium, and other harmful substances
3: Using ultra-bright imported LED chips as the light source, built-in microcomputer chips, can be programmed and controlled arbitrarily for multiple synchronous changes, and can also realize colorful gradients, jumps, scanning, and can change various pictures and texts
4: Structural waterproof design, which solves the problem of damage to lamps and engineering quality of traditional LED outdoor lamps due to entering

Dimension Drawing

Installation

Application
