Meanwell ELG LED Switching Power Supply 12v 24v 50V Waterproof Led Dimmable Driver

Meanwell ELG Series LED Power Supply

  • Wattage: 75-300W
  • Applicateion for street light, architectural light, Pixel light,flood light, Linear Light, Neon Light and LED Strip

Specification

Meanwell power supply : Product Feature



Meanwell ELG LED Switching Power Supply is a brand of high-quality power supplies that are widely used in various industries, including LED lighting, medical equipment, and industrial automation. Meanwell is a Taiwanese-based company that has been in operation since 1982 and has established itself as a leader in the power supply industry.

Meanwell power supplies are known for their high reliability, durability, and efficiency, making them a popular choice for LED lighting applications. They offer a wide range of power supply models that are designed to meet various voltage and current requirements. These power supplies are available in both AC-DC and DC-DC configurations and are designed to convert AC power to DC power with minimal energy loss.

Meanwell ELG-240 LED Switching Power Supply 12v 24v 50V 40w 50W 75W 100W 150W 200W 240W 250w 300W Waterproof Led Dimmable Driver

Features:

100~305VAC input range

Constant current (C.C.) output

Constant power (C.P.) output

Built-in active PFC function

No load/standby power consumption <0.5W

Metal case, IP67/IP65 design for indoor or outdoor installations

Function options:
output adjustable via potentiometer; 3 in 1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-to-off); smart timer dimming; DALI; auxiliary DC output (ELG-150-C BE-Type)

Type “HL” LED drivers for use in Class I, Division 2 hazardous (Classified) location luminaries

Suitable for LED street lighting and outdoor LED lighting

5 years warranty

Meanwell ELG LED Switching Power Supply : Packaging information

ELG-75W 180*63*35.5mm (L*W*H) 0.8Kg;16pcs/13.4Kg/0.67CUFT
ELG-100W 199*63*35.5 mm (L*W*H) 0.85kg; 16pcs/14.2kg/0.72CUFT
ELG-150W 219*63*35.5mm(L*W*H) 0.95kg; 16pcs/16.0kg/0.77CUFT
ELG-200W 244*71*37.5 mm (L*W*H) 1.22Kg; 12pcs /15.2kg / 0.72CUFT
ELG-240W 244*71*37.5 mm (L*W*H) 1.22Kg; 12pcs /15.2kg / 0.72CUFT
ELG-300W 246*77*39.5mm (L*W*H) 1.45Kg;9pcs/14Kg/0.76CUFT
