A 3D flexible LED pixel mesh screen is a type of LED display that features a mesh of flexible LED panels that can be bent and shaped to create three-dimensional structures. The mesh screen is made up of a series of LED pixels that can be individually controlled to create various lighting effects and displays.
| Item | GPX 3D MINI Flexible LED Mesh screen | ||
| specifications | P50 | P100 | P150 |
| Application | Indoor/outdoor | Indoor/outdoor | Indoor/outdoor |
| Installation | Flexible PVC tape support | ||
| Load wire | 5.0mmWire fixing (Single module 2pcs) | 5.0mmWire fixing (Single module 2pcs) | 5.0mmWire fixing (Single module 2pcs) |
| Single module width | 0.5meter/Piece | 0.5meter/Piece | 0.5meter/Piece |
| Max length of single row | 6m | 12m | 18m |
| No. of lights per square meter | 400led/m2 | 100led/m2 | 44led/m2 |
| Power per square meter | 120W/m2 | 30W/m2 | 13.2W/m2 |
| Per square meter weight | 2.25KG/m2 | 0.55KG/m2 | 0.23KG/m2 |
| Lamp flatness | < 1mm | <1mm | <1mm |
| Viewing distance | >50meter | >100meter | >150meter |
| Viewing angle | Within 140° | Within 140° | Within 140° |
| Signal transmission distance | Within 15 meters from the controller to the headlight | ||
| Display mode | Computer/master synchronization | Computer/master synchronization | Computer/master synchronization |
| Overall transparency | 81.2% | 92.3% | 96.2% |
1. With its new flexible design/neoteric grid structure, foldable, collapsible, lightweight appearance, and good environmental adaptability, the Pixel Mesh LED screen is a new innovative LED product.
2. Using innovative installation methods, you can decorate your LED grid screen quickly, easily, and with flexible options;
3. Processing technology for high-speed video, able to show videos of all types, and unique effects, which are highly captivating
The flexible nature of the LED panels allows for the creation of unique and dynamic designs. The LED pixel mesh screens are ideal for use in various applications, including stage and event lighting, architectural lighting, and advertising.
The 3D flexible LED pixel mesh screen is lightweight and can be easily transported and installed. The screens can be designed to fit the specific needs of the project, and the LED pixels can be controlled using a DMX protocol to create custom lighting effects.
Overall, the 3D flexible LED pixel mesh screen is a versatile and dynamic LED display that can be used in a variety of applications to create unique and visually stunning lighting displays.
